Spline Gauges 30dec PA suit Involute Splines 15 common DP sizes
- SKU:
- PTO-SPLG
- Availability:
- If in stock (Please see below price for current stock level) - Ships same day if ordered between Monday-Friday & before 3.30PM Victorian time.
- Shipping:
- Calculated at Checkout
MSRP:
$379.95
$349.95
— You save
$30.00
Description
30DEG Pressure Angle Involute Spline Gauge
Made from Stainless Steel & Made in the USA
15 common sizes PG-S1-GC
Comes supplied in leather pouch
Each gauge is clearly marked for easy identification
Extremely hard to source
Includes the following:
2.5/5-3/6-4/8-5/10-6/12-7/14-8/16-10/20-12/24-16/32-20/40-24/48-32/64-40/80 & 48/96
